Mono Block Class D Amplifier

Features

Frequency: 20Hz-250Hz

Input sensitivity: 200mV-6V

LPF: 30 Hz-250Hz

Bass boost: variable 0-6dB

Subsonic filter: 15Hz-50Hz

High-level input and variable Gain control

Short, thermal and overload protection

Product Description

NSMR-1.1000D is a high-performance mono Class D car amplifier designed for audiophiles seeking powerful bass and system stability. It delivers powerful output under varying loads: 450W RMS at 4 ohms, 680W RMS at 2 ohms, and up to 1000W RMS at 1 ohm. This powerful output easily drives a wide range of high-power subwoofers, injecting powerful low-frequency energy into your car's system. It offers enhanced energy efficiency and lower heat generation, ensuring stability even during extended playback. A 15Hz to 50Hz subsonic filter effectively eliminates unwanted low frequencies, protecting the speakers while enhancing sound clarity. A variable bass boost function (0–6dB) allows users to customize the bass impact and enhance the listening experience.
