2 Channel Class D Power Amplifier with Bluetooth Receiver

NSTE-2120 2-Channel full-range class D power amplifier is designed specifically for in-car audio systems, motorcycle audio systems, and outdoor mobile audio environments. Combining outstanding power performance, robust protection, and installation flexibility, it's an ideal choice for users demanding both high-quality sound and adaptability to harsh environments. Its compact design allows for easy installation in tight spaces, making it particularly suitable for space-sensitive applications such as motorcycles, ATVs, and electric vehicles. The exterior utilizes a TE waterproof connector, and the overall system achieves an IPX4 to IPX5 rating, offering excellent water and dust resistance and stable operation in rainy, humid, or dusty environments. While the crossover also features a fixed configuration, its preset parameters meet the driving requirements of mainstream speakers, ensuring a frequency response range of 20Hz to 20kHz, achieving full-band sound reproduction and delivering exceptional performance from deep bass to crisp high frequencies.

NSTE-2045 is a highly efficient, compact, two-channel Class D power amplifier designed for audio systems such as motorcycles, electric vehicles, UTVs, and ATVs, which have strict requirements on size while requiring both weather resistance and sound quality. The output power per channel is 45W RMS (4 ohm load, 14.4V power supply), and the total harmonic distortion is controlled within 1%, ensuring clear and full sound quality, meeting the needs of daily entertainment playback and commuting. Its operating frequency range covers 20Hz to 20KHz, fully restoring the full-band sound effects, with excellent performance from low-frequency shock to high-frequency details. In terms of safety protection, the NSTE-2045 is equipped with overheating, overload, and short-circuit protection mechanisms, which can automatically cut off the power in the event of electrical anomalies or excessively high ambient temperatures, effectively avoiding equipment damage and extending the product life.

NSTE-4020-BT is a four-channel, full-band Class D power amplifier with integrated Bluetooth receiver. Designed for applications such as motorcycles, electric vehicles, ATVs, and UTVs, where size, durability, and a wireless audio experience are paramount, this amplifier not only delivers efficient and stable amplification but also incorporates wireless connectivity, significantly enhancing ease of use and system integration. Each channel delivers 20W RMS output into a 2-ohm load (within 1% total harmonic distortion). Its high-performance, full-band Class D amplification architecture delivers clear, balanced, and powerful sound, covering the entire 20Hz to 20kHz frequency range and ensuring accurate rendering of musical details. For waterproofing, the product utilizes TE's professional-grade waterproof connectors and achieves IPX4 to IPX5 ratings, ensuring stable and reliable operation in humid, dusty, and even lightly splashed environments. Equipped with a Bluetooth wireless receiver module, users can easily connect their smartphones, tablets, or other Bluetooth devices to the amplifier, allowing them to stream their favorite music without wiring, greatly enhancing operational freedom and entertainment experience.

NSM-2020 is a miniature, two-channel Class D car amplifier measuring just 110mm (length) x 92mm (width) x 45mm (height). This significantly reduces installation space and is ideal for installation in confined areas such as under the dashboard, next to seats, or other discreet locations, while still delivering excellent performance. Its wide frequency response, covering 20Hz to 20kHz, faithfully reproduces rich details from bass to treble, satisfying the needs of a wide range of musical styles. The amplifier supports high- and low-level input switching for robust compatibility, making it easily compatible with both original audio sources and external devices. A signal-sensing function enables automatic power-on, and a built-in 12V remote output facilitates control and integration with other devices.

NSLBM-2150 is a high-performance, two-channel, full-range Class D car amplifier designed for users who demand powerful sound quality and exceptional protection. Its IPX5 waterproof rating and rugged mechanical construction (ME structure) ensure stable operation in harsh environments, making it ideal for outdoor and in-car audio system upgrades. The NSLBM-2150 delivers 100W RMS power per channel into a 4-ohm load, increasing to 150W RMS into a 2-ohm load, with sub-1% distortion, delivering a clear, rich, and dynamic audio experience, meeting the dual power and sound quality demands of various audio systems. The product features a pre-wired pigtail harness, simplifying installation and reducing wiring complexity. A DIP switch control panel allows for flexible crossover mode selection, and a built-in low-pass filter (LPF) with a selectable 120Hz or 80Hz setting allows users to adjust the frequency response and optimize sound quality based on their speaker configuration.

NSXP-2120 is a high-performance, two-channel Class D car amplifier designed for in-car audio systems that demand clear sound quality and space-saving features. This two-channel Class D amplifier delivers 2 x 70W RMS power into a 4-ohm load and 2 x 120W RMS into a 2-ohm load, with total harmonic distortion (THD) kept to less than 1%, ensuring pure, dynamic sound. It's ideal for driving mid-range and high-frequency speakers, delivering a more three-dimensional and natural musical performance. It can be conveniently installed concealed under a car seat or in the trunk, minimizing space and providing greater installation flexibility for limited interior space. It supports both RCA low-level and high-level inputs, and an input level selector switch allows for easy integration with both original and modified head units, further enhancing compatibility.
